5/8" Mild Steel Headed Concrete Anchor
These general purpose concrete anchors are used in all types of concrete connections. They can be welded to a flat surface or to the inside or outside of an angle. It is made of low carbon steel, ASTM A29, 1010-1020.
Also available in:
1/4″
3/8
1/2″
Or:
Stainless Steel
| Diameter | Length | TRU-WELD Part Number | Pieces Per Box | Boxes Per Pallet | Pieces Per Pallet | Box Weight | Pallet Weight | 1,000 Piece Weight |
|---|---|---|---|---|---|---|---|---|
|
5/8 |
1-7/16 |
CA10-023-11 |
400 |
27 |
10,800 |
85 lbs. |
2,295 lbs. |
208 lbs. |
|
5/8 |
1-11/16 |
CA10-027-11 |
325 |
27 |
8,775 |
77 lbs. |
2,079 lbs. |
227 lbs. |
|
5/8 |
1-15/16 |
CA10-031-11 |
300 |
27 |
8,100 |
78 lbs. |
2,106 lbs. |
248 lbs. |
|
5/8 |
2-1/8 |
CA10-034-11 |
250 |
27 |
6,750 |
68 lbs. |
1,836 lbs. |
264 lbs. |
|
5/8 |
2-3/16 |
CA10-035-11 |
250 |
27 |
6,750 |
71 lbs. |
1,917 lbs. |
270 lbs. |
|
5/8 |
2-11/16 |
CA10-043-11 |
250 |
27 |
6,750 |
81 lbs. |
2,187 lbs. |
319 lbs. |
|
5/8 |
3-3/16 |
CA10-051-11 |
200 |
27 |
5,400 |
75 lbs. |
2,025 lbs. |
363 lbs. |
|
5/8 |
3-11/16 |
CA10-059-11 |
150 |
27 |
4,050 |
75 lbs. |
1,674 lbs. |
398 lbs. |
|
5/8 |
4-3/16 |
CA10-067-11 |
150 |
27 |
4,050 |
69 lbs. |
1,863 lbs. |
444 lbs. |
|
5/8 |
4-11/16 |
CA10-075-11 |
125 |
27 |
3,375 |
63 lbs. |
1,701 lbs. |
487 lbs. |
|
5/8 |
5-3/16 |
CA10-083-11 |
100 |
27 |
2,700 |
55 lbs. |
1,485 lbs. |
530 lbs. |
|
5/8 |
6-9/16 |
CA10-105-11 |
80 |
27 |
2,160 |
52 lbs. |
1,404 lbs. |
650 lbs. |
|
5/8 |
8-3/16 |
CA10-131-11 |
50 |
27 |
1350 |
40 lbs. |
1080 lbs. |
800 lbs. |
|
5/8 |
9-3/16 |
CA10-147-11 |
125 |
9 |
1125 |
109 lbs. |
981 lbs. |
872 lbs. |
