The TW6950 is a fully integrated 50Hz stud welding system with two digital controls for time and current. The system was designed to meet the most challenging stud welding jobs.
NEW PRO-TECH’D technology protects the gun circuitry
NEW Improved user interface for more intuitive setup
NEW Factory presets and user customizable presets
NEW Improved weld control
Features/Included
- Power supply Controller, TWE17000 Heavy Duty stud gun, 50 feet of 4/0 weld and control cable and 25 feet of 4/0 ground cable w/ HD clamp
TW6950 Specifications
Size/Dimension:
Height 28” (711.2mm)
Width 29” (736.6mm)
Length 36” (914.4mm)
Width 29” (736.6mm)
Length 36” (914.4mm)
Weight:
760 Lbs (345Kg)
Weld Range:
1/4” to 1” diameter
Duty Cycle:
1/4” through 5/8" - unlimited
3/4" - 18 to 24 per minute
7/8” - 12 to 14 per minute
1” - 6 to 8 per minute
* Enhanced duty cycle for production requirements.
* Powerful output for even the largest diameter jobs.
* Stepless time and current control allow for infinite settings for fine tuning the welding output.
* Safety welding interlock
* Keeps system from double triggering.
* Stud Job Counter that can be reset for every job.
3/4" - 18 to 24 per minute
7/8” - 12 to 14 per minute
1” - 6 to 8 per minute
* Enhanced duty cycle for production requirements.
* Powerful output for even the largest diameter jobs.
* Stepless time and current control allow for infinite settings for fine tuning the welding output.
* Safety welding interlock
* Keeps system from double triggering.
* Stud Job Counter that can be reset for every job.
Input Voltage:
380 / 400 VAC 3 Phase 50Hz
Fusing Requirement:
(slow acting)
380 / 100 Amps
400 / 100 Amps
380 / 100 Amps
400 / 100 Amps
